Filmetrics Model 205-0020
OEM Part #:
205-0020
OEM Name:
Filmetrics
ID #:
5117
Product Details:
FILMETRICS F20 THIN FILM ANALYZER consisting of:
- Model: F20 - Wavelength Range: 380-1050 nm - Thickness Measurement Range: 15 nm - 100 μm - Thickness Req'd to Measure n and k*: 100 nm and up - Spot Size: Standard 1.5mm, Optional down to 20 μm - Sample Size: From 1mm in diameter and up - Light Source: Tungsten-Halogen - PC Tower - Monitor
Condition:
As-Is / Where-Is Condition.
Description:
Filmetrics Model F20
